Pilot Operated Safety Valve Manufacturer

  • Darshan Valve is a well‑versed manufacturer of Pilot Operated Safety Valves. These valves are engineered for reliable overpressure protection in critical industrial systems.
    • Pilot Operated Safety Valve
    Pilot Operated Safety Valve
  • Commonly used in petroleum, natural gas, electric power, metallurgy, and burning gas applications, these valves ensure bubble‑tight shut‑off under normal conditions and provide emergency relief during overpressure events.

Pilot‑Operated Safety Valve – Features

  • Easy operation
  • Only the pilot needs to be set
  • Blowdown can be externally adjusted

How It Works

The pilot valve senses system pressure and controls the main valve accordingly. When pressure exceeds the set limit, the pilot actuates the main valve, allowing excess pressure to escape. Once the system pressure returns to safe levels, the main valve closes tightly, ensuring leak‑free operation and continuous protection.

How it works - Pilot Safety Valve

Technical Specifications

Material

Stainless Steel / Alloy Steel / Cast Steel

Pressure Range

5 – 400 bar

Temperature Range

–40°C to 450°C

Size Range

1” to 12” (larger on request)

Operation

Pilot‑operated with adjustable blowdown

Standards

API / ASME / ISO

Applications

  • Petroleum & Natural Gas – Protects pipelines and processing equipment from overpressure.
  • Power Plants – Ensures safety of steam and gas systems in energy generation.
  • Metallurgy Industry – Provides safe relief in furnaces and high‑pressure systems.
  • Chemical & Process Plants – Maintains safe operation during pressure fluctuations.
  • Gas Distribution Systems – Reliable overpressure protection in storage and transfer.
  • Marine & Offshore – Secures high‑pressure equipment in critical environments.

Advantages

High Accuracy

Precise pressure control through pilot mechanism.

Bubble‑Tight Shutoff

Zero leakage under normal conditions.

Adjustable Blowdown

Easy external adjustment for system flexibility.

Reliability

Consistent and repeatable pressure relief action.

Durability

Withstands harsh industrial environments.

Safety Compliance

Meets international safety and performance standards.

Installation & Maintenance Tips

  • Install vertically for best performance.
  • Keep pilot lines clean and free from blockages.
  • Ensure easy accessibility for inspection and testing.
  • Regularly check pilot and main valve for leaks.
  • Test blowdown adjustment periodically.
  • Replace worn‑out seals or springs as per service schedule.
